Single place Part 103 ultralights in the United States are defined as single
place ultralight aircraft that weigh 254 lbs or less, have a stall speed
not more than 24 knots, a top
speed of 55 knots, and carry no more than 5 gallons of fuel. To fly a
legal Part 103
ultralight aircraft in the United States the pilot does not require a
pilot license.
Single place aircraft weighing more than 254 lbs. in the U.S. require a
pilots license and must be built as experimental, amateur built,
homebuilt aircraft. These include weight shift aircraft, more commonly
known as trikes, powered parachutes, and powered para-gliders.
Single place ultralights in Canada can weigh up to 1200 lbs. and an
ultralight pilots license is required to fly them.
|
|
|
|
|
|
|
|
Fisher Avenger pictures and
specifications, images of the
Fisher Avenger amateur built experimental homebuilt aircraft
specifications and data.
|
 |
Fisher Avenger pictures, images
and specifications for the
Fisher Avenger
amateur built experimental homebuilt aircraft.
|
|
|
Fisher Avenger
Performance Specifications
|
| Horsepower: |
52 hp |
| Fuel Capacity: |
5 gal |
19 L |
| Range: |
130 nm |
241 km |
150 mi |
| Cruise: |
52 kts |
96 kmh |
60 mph |
| Stall: |
24 kts |
44 kmh |
28 mph |
| Climb: |
900 ft/min |
4.6 m/sec |
| Takeoff Distance: |
100 ft |
30 m |
| Landing Distance: |
200 ft |
61 m |
Fisher Avenger
Specifications
|
|
| Gross Weight: |
600 lbs |
272 kg |
| Empty Weight: |
280 lbs |
127 kg |
| Useful Load: |
320 lbs |
145 kg |
| Wingspan: |
27 ft |
8.23 m |
|
| Length: |
16.25 ft |
4.95 m |
| Height: |
5 ft |
1.52 m |
|
Fisher Avenger
Experimental Aircraft |
Fisher Avenger
Experimental Homebuilt Aircraft |
|
|
|
|
To view the
pictures, images of the Fisher Avenger click on the smaller
images and they will enlarge. To return to the index page for the Fisher Avenger click on Fisher Avenger Index link, to view
video of the Fisher Avenger click on the Video link, to
return to the Main Index click on the UltralightNews link. |
|
|
|
|
|
|
|
