Electric Skyway - Flying
By Dan Johnson, July 17, 2013
was a little nervous, I admit. Oh, I wasn't worried about flying
the eSpyder as an airplane. Many years ago I logged plenty of
hours in a Flightstar single place ultralight and
this was essentially the same airplane. Except it wasn't
identical; this one was powered by an electric motor and it's
funny how that changes everything.
Like most of you, I only have experience with gasoline engines
(though I have logged many hours of soaring time with no engine
whatsoever). So, I have the usual set of knowledge and reflexes
about fuel consumption, engine noise, power settings, climb
rates ... and the sounds of all these things. It's all different
on an electric airplane.
Much as I had awaited this opportunity, I found myself
apprehensive about the new experience. I've had three two-stroke
engines go silent on me and I simply didn't know exactly what to
expect from an electric motor. Spoiler alert: I needn't have
My first electric flight ... finally! I'm told I'm the first
journalist to fly the current iteration of eSpyder.
I have access to an electric golf cart. That's a good place to
start as it's quite similar, in sound and smoothness. Yet as
with the golf cart and like many who contemplate buying an
electric car - not a hybrid, but a pure, plug-in electric - I
found myself taxiing to the runway at Cable Airport in
California experiencing what experts call "range anxiety." How
long before the batteries run out and the engine ... er, motor,
The numbers are all different. Fuel, or better said, energy is
measured in volts. I was starting out with full tanks ... er, a
full charge, at 74 volts. I had a handy checklist strapped to my
left leg (see below) and I was trying to wrap my brain around
the unfamiliar numbers. A full charge was 74 volts but at 58
volts the motor would shut down thanks to energy management and
So, 74 is full and 58 is empty. Power settings refer to a value
expressed in KW. I was to climb at 25 KW (about 32 horsepower)
for no more than two minutes, although my check-out pilot Tony
Settember assured me test pilots had flown eSpyder for an hour
with the throttle wide open. Cruise climb is done at 18-20 KW
and cruising is done at 10-12 KW. You use a regular throttle,
except it feels more like a lever-operated rheostat (a volume
knob, basically) with little resistance throughout its range
I realized that the "language" of electric propulsion is
different. Like most pilots I'm used to checklists and I
willingly paid attention to the one strapped on my left leg.
Following is verbatim from the checklist for eSpyder N12XW:
1. Switch on (Left side of panel)
2. Plug in EMERGENCY SHUT-OFF (Left side on floor)
3. Switch off (Left side of panel)
4. Turn key ON Right side of panel (wait one minute)
5. Turn on screen (Button center bottom of screen)
6. Unlock throttle (Push green button on throttle in)
7. Pull CHUTE SAFETY PIN (Stow in safe place)
8. Fasten Safety Harness
9. Run Up Minimums: 25 KW, 67 Volts
- Take off 73 Volts (not below 72 Volts)
- Return to field 62 Volts
- Land by 60 Volts
- Motor cuts off at 58 Volts
- 25 KW for 2 Minutes (Take off power)
- 18 - 20 KW Climb power
- 10 - 12 KW Cruise power
To understand more about eSpyder powered by Yuneec, check out
the various power component parts.
carries two Lithium-Ion battery packs that weigh about 150
pounds, according to Tony. The airplane has to be certified as
Experimental Amateur Built
in the USA for now, though Germans and other Europeans can use
the new DULV certification to buy a ready-to-fly model. The good
news is build time is well under 100 hours; it's primarily a
So, save a little and learn more about your new electric
airplane. GreenWing will market a fully built aircraft when FAA
figures out how they'll handle these "new" powerplants. You see,
when the SP/LSA regulations were issued way back in 2004, FAA
didn't want turbine engines making their way onto LSA, so they
specified reciprocating engines only. However, that lack of
foresight left out the electric development. ASTM hashed out and
finally passed a standard for electric propulsion so the
industry is ready.
The likeliest outcome is that FAA may issue an exemption. The
agency can learn about electric propulsion in this way and
hopefully a rule change will later allow electric airplanes. You
can read all the tech specs at Yuneec while GreenWing finishes
airport (KCCB), according to longtime resident and Foothills
Flying Club operator Tony Settember, has for decades been a
family owned airfield, the largest such public use airport in
the world, with some 400 airplanes calling it home. As we drove
in, the place seemed surrounded by quarry pits, not the
friendliest-looking location to someone who was thinking about
engine- ... er, motor-out landings. As Tony patiently explained,
the area is actually quite accommodating as those big pits have
immense wide roads running around them for an easy landing
should the need arise.
|As soon as I went aloft, I saw what he meant and I relaxed into
the flight. To begin, I went right around the pattern and made a
landing, just to assure myself. With light, gusting winds only a
shallow angle off the runway, my landing went well, even though
I allowed a bit of drift to carry me off the centerline.
that second take off after a touch and go, the voltage supply
read 60 plus a decimal. Since the checklist shows "Return to
field at 62 volts" my concern returned. I forced myself to
recall Tony's excellent briefing when he said not to worry about
this, that when you back off full power the voltage would rise
again. It did and so I set off for yonder dam, flying a few
miles north across several
open-pit rock quarries that also function as part of the water
percolation system for the area. Sure enough the voltage came
back up a bit. Twelve minutes into the flight, the voltage read
66.33 and I kept an eye on it to realize that voltage dropped
very slowly. Twenty-five minutes into the flight I still had 64
and a decimal, so I further relaxed my range anxiety.
The little eSpyder was the charming ultralight-type airplane I
recalled from my past and I thoroughly enjoyed the flight. I
banked around the foothills near the dam and kept pulling the
earcup away from my head to easily hear ground traffic while the
prop purred at an 11 KW power setting. A low-pitched whine - not
remotely like the high-pitch scream of a two-stroke - proved to
my ears that the motor was actually working. Otherwise, the
near-silence is golden. At a field where no radio communication
was necessary, I'd ditch the headset and enjoy that amazing
quietness, second only to an unpowered sailplane or hang glider.
Yet it was reassuring that with a flick of the throttle, the
purring intensified every so slightly and up we went. In all,
eSpyder proved an addicting experience. I want more! I think
many pilots should experience electric flight and it's here now,
in GreenWing's eSpyder powered by Yuneec. I hope you can go to
Oshkosh and visit the GreenWing gang (main display in spaces 406
& 417 or flying display in Ultralight 938).
