Advanced
Aviation Cobra A, Advanced Aviation Cobra B
Advanced Aviation Cobra was produced in two models
the A and B model. The basic difference was the addition of
ailerons and less dihedral in the B model. The Cobra is seater,
single pusher engine, high wing wire braced craft.
Empty Weight:
218 lbs.
Gross Weight:
468 lbs.
Wing Span:
35 ft.
Wing Area:
160 sq ft.
Engine:
430 Cayuna
Cruise Speed:
50 mph.
Stall Speed:
25 mph.
VNE:
75 mph.
Construction:
alum/tube/dacron
Building time:
75 hrs.
Construction features aluminum tube and dacron
sailcloth, bolt together construction, wire braced with a double
surface wing. The control system is conventional 3-axis control
system.
Tricycle landing gear, uses torsion bar
suspension, and the plane could be equipped with an optional
steerable nose wheel with brakes on nosewheel.
Earlier models used the Cuyuna engine with a
planetary reduction drive, later models came equipped with the
Rotax 377/447 and an HP Model 503 Rotax with a 2.58 to 1 reduction
drive.
Original manufacturer Advanced Aviation.
