Powered by a 250cc, 2-cycle, Zenoah Z-25BI
engine. Developing 20 HP at 6500 RPM with direct mounted prop.
Engine weight
including air air cleaner, propeller hub and recoil starter assembly - 50 lbs.
PROPELLER:
36” Dia. with 10” pitch laminated wood (direct drive) 54”
Dia. with 20” pitch laminated wood (reduction drive)
WEIGHT:
Empty - 170 lbs Gross - 370 lbs.
DIMENSIONS:
Wing Span - 34 ft
Wing Cord - 52 inch.
Wing Area - 128 sq. ft
Wing Loading - 2.5 - 3.0 lbs. per
sq. ft.
Length - 18 ft.
PERFORMANCE:
Rate of climb (Full throttle) - 400 FPM
Fuel Capacity - 5 gal.
Fuel Consumption 1 1/2 gal. per hr.
Top Speed 45 - 50 MPH
Take Off/Landing Speed 25-28 MPH
Stall Speed - 22-24 MPH
Take Off Roll - 300 ft surfaced/400 ft grass
Landing Roll - 150 ft surfaced/60 ft grass
Sink Rate - 225 FPM (approx.) L:D -
10:1
Estimated Set Up Time - 10-20 Min.
Original manufacturer Maxair
